Maximum core assembly weight: 5 kg
Maximum flange diameter on the turbine side: 150 mm
Maximum turbine wheel diameter: 130 mm
Maximum compressor wheel diameter: 153 mm
Minimum achievable residual unbalance: 0,05 gmm
Machine frame made of mineral casting:
Non-sensitive to external interferences,
No separate foundation required
CAB measuring unit technology:
Schenck standard with PC-technology
according to industry standards
and with touchscreen terminal
Schenck Service:
Global service network with
24-hour helpdesk availability
- Unbalance measurement on the turbocharger core assembly
- Automatic speed control
- 1- and 2-plane measurement
- High-end software for analysis of the core assembly
- Peak hold frequency spectrum and waterfall diagram
Advantages at a glance
- Highest degree of measurement accuracy
- Easy operation thanks to intuitive menu guide
- Extensive evaluation, export and analysis options
- Highest safety standards as per CE
- Compact monoblock machine made of mineral casting
- Broad range of applications (passenger car, truck, marine)
- Considerable economic efficiency (quick change over to small batch sizes)
- Fast and precise determination of the unbalance
